The ROPS-certified cab provides additional protection for the operator and enhances safety during daily use.
Sweeping performance
Maximum sweeping performance.
Maximum sweeping performance.
Optimized down to the last detail.
The direct airflow and the front-mounted fan minimize flow losses. As a result, the machine achieves high suction power even at low speeds - and reduces energy consumption during operation.
The 900 mm-wide suction inlet picks up more debris with each pass. This increases cleaning productivity and reduces the number of passes required.
The enlarged suction pipe diameter of 250 mm improves material flow and ensures reliable handling even of coarse material. For high performance even under demanding conditions.
The retractable disc brushes avoid obstacles in a controlled manner thanks to a two-stage spring-loaded collision protection system and are automatically returned to their working position. This reduces damage and wear and eases the driver’s workload during daily operations.
Debris Bin
Durable debris bin.
Durable debris bin.
Designed for durability.
High-strength steel walls and stainless steel floor
Solidly welded base for high stability
Optional stainless steel version
Electric leaf sieve lowering mechanism
Optimized airflow in the container
Standard Tilt-and-Dump System
With a dumping height of 1050 mm and a dumping angle of 51°, the waste container can be emptied reliably and efficiently into standard containers.
Optional high-level disposal
The built-in scissor lift raises the bin up to 1820 mm and moves it closer to the container. For clean and safe emptying.
257°
Panoramic
glazing
glazing
2.8 m²
Windshield
area
area
ROPS
Safety
booth
booth
AGR
Ergonomics-
certified
certified
Workplace
Maximum visibility.
Maximum visibility.
A comfortable workspace.
Ergonomically designed down to the last detail - experience the cabin interactively.
Drive Options
Diesel or electric.
Diesel or electric.
Ready for any job.
Efficient diesel or sustainable electric drive: both variants offer the same tried-and-tested sweeping technology and identical sweeping performance.
Cleango 550
| Engine | 6-cylinder diesel engine |
|---|---|
| Performance | 125 kW (170 PS) |
| Torque | 600 Nm @ 1'200 rpm |
| Emission | Euro 6e / Stage V |
| Efficiency | Low fuel consumption |
eCleango 550 – Fully Electric
| Drive | Fully electric, up to 128 kW |
|---|---|
| Battery | 102 kWh / opt. 153 kWh |
| Operation | Up to 10 hours |
| Charging | AC 22 kW / DC 80 kW CCS |
| Charging time | AC ≈3-4 h / DC ≈1 h |
See for yourself the performance, comfort, and efficiency.
The Cleango 550 in action.
Ergonomically designed down to the last detail - experience the cabin interactively.
Dust-free working
Effective dust control. Minimal water consumption.
Two spray nozzles per disc brush and additional nozzles in the suction shaft and suction pipe ensure targeted dust suppression. The water volume can be adjusted via the central touchscreen display to suit weather conditions, thereby conserving resources in a targeted manner. Optionally, the pressurized recirculating water system with a 300-liter service water tank enables the reuse of filtered water, reduces fresh water consumption, and increases the operating range.
Water System
The right water system
The right water system
for every application.
Basic water system
PE Fresh Water Tanks
700 l total volume in three corrosion-resistant PE tanks
High-Performance Water Pump
3.4 bar pressure at a flow rate of 15 l/min
Spray Nozzles & Humidification
Two spray nozzles per disc brush and additional nozzles in the suction chute - targeted moistening to reduce dust formation
Filling port
A centrally positioned filling port, including a free flow path, allows for easy and convenient filling.
Optional: full features
Additional water tanks
An additional 700 l and 400 l — for a total volume of up to 1,800 l
High-pressure pump
15 l/min flow rate, up to 150 bar pressure
Hand-held spray gun with hose reel
17-meter range for manual cleaning of hard-to-reach areas
Pressure circulating water system
A 300-liter service water tank and a separate wastewater pump for reusing filtered recirculated water.
Chassis
A solid foundation for safe work.
The optimized suspension system ensures a smooth ride, high stability, and reduced vibrations - even on uneven surfaces.
Optimized suspension system for a smooth ride
Reduced vibrations on uneven surfaces
High driving stability during operation
Designed to comply with relevant vibration limits
Configuration
Wide range of options.
Configure your Cleango 550 to meet your needs.
Contact
Contact us now.
Experience a personalized live demo right on site, take advantage of a no-obligation consultation, and receive a customized quote tailored precisely to your needs. A test drive is also available upon request.
